Marantz AV7701 - Preout Pcb Unit Assy

250
PREOUT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D6845-6847 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D6848 90M-HD302380R DIODE , ZENER ,1/2W, 3.6V CVDZJ3.6BT 1
D9308,9309 943209001080S DIODE , CHIP , SWITCHING 1SS355 CVD1SS355T 1
IC931,932 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI 1
IC934 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI 1
IC935 00D2631099006 I.C,REGULATOR(-5V,T0220IS) CVIKIA7905PI 1
IC936 943231102150S I.C , REGULATOR(8V ,1A /TO-220F-4) CVINJM2388F08 1
s
IC937 00D2631251006 I.C,REGULATOR(-8V,T0220IS) CVIKIA7908PI 1
Q6843,6844 943214500030S T.R , MUTE CVTINC2001AC1 1
Q6873,6874 943214500030S T.R , MUTE CVTINC2001AC1 1
CAPACITORS GROUP
C6707,6708 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C6709,6710 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C6727,6728 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C6729,6730 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C6757,6758 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C6759,6760 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C6777,6778 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C6779,6780 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C6805 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C6806 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C6829,6830 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C6833,6834 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C6835,6836 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C6845 nsp CAP, ELECT(50V/0.47uF) CCEA1HHR47T 1
C6849 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C6859,6860 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C6863,6864 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C6865,6866 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C6875 nsp CAP, ELECT(50V/0.47uF) CCEA1HHR47T 1
C6891,6892 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C6893,6894 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C9301 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C9302 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C9303 nsp CAP, ELECT(16V/100uF) N/K CCEA1CH101T 1
C9304,9305 nsp CAP, ELECT(50V/10uF) N/K CCEA1HH100T 1
C9306 943134010600S CAP, ELECT(16V/3300uF) CCEA1CH332E 1
C9307 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C9308 943134010600S CAP, ELECT(16V/3300uF) CCEA1CH332E 1
C9309 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C9310 90M-OA000620R CAP , ELECT CCEA1EH682E 1
C9311 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C9312 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 1
C9316 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 1
RESISTORS GROUP
R5647 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5697 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5747 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5847 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5897 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5947 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5997 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6703-6706 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R6709,6710 00MNN05104610 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6711,6712 00MNN05221610 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R6723-6726 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R6729,6730 00MNN05104610 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
