Marantz AV7701 - Heat Sink Assy

16
2. HEAT SINK ASSY
(1) Remove the screws.
(2) Cut the wire clamp band, then remove the screws. Disconnect the connector wires.
CABINET TOP
HEAT SINK ASSY
→
Proceeding :
View from the bottom
Shooting direction: D
Shooting direction: C
