Marantz AV7701 - Input Pcb Unit Assy

219
INPUT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D4779,4780 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
IC466 00D2631289900
I.C , OPAMP(DUAL/LOW NOISE)_Copper
Z4580MTR-E1-CU
CVIAZ4580MTR-E1-CU 1
IC471 235810045600S I.C , 8CH VOLUME CVIR2A15220FP 1
IC481-483 00D2631289900
I.C , OPAMP(DUAL/LOW NOISE)_Copper
Z4580MTR-E1-CU
CVIAZ4580MTR-E1-CU 1
IC484 00D2623727904 I.C , 2CH VOLUME CVINJW1194V 1
IC486-488 00D2631289900
I.C , OPAMP(DUAL/LOW NOISE)_Copper
Z4580MTR-E1-CU
CVIAZ4580MTR-E1-CU 1
IC489 00D2623727904 I.C , 2CH VOLUME CVINJW1194V 1
CAPACITORS GROUP
C4603,4604 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C4607,4608 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C4613,4614 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C4617,4618 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C4627,4628 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C4633,4634 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C4637,4638 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C4643,4644 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C4647,4648 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C4663,4664 nsp
CAP, ELECT (10uF/50V, 6.3X11, RA3)
00MF3#8P-T2
CCEA1HRA38P100T 1
C4675,4676 nsp
CAP, ELECT(16V/220uF),ELNA/RA3 A3-
16V221MF3#8P-T2
CCEA1CRA3221T 1
C4677,4678 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C4679,4680 nsp CAP, MYLAR(50V/0.022uF/J) HCQI1H223JZT 1
C4681,4682 943139001260S EOL item CAP, MYLAR(50V/6800pF/J) HCQI1H682JZT 1
C4687-4690 nsp
CAP, ELECT (10uF/50V, 6.3X11, RA3)
00MF3#8P-T2
CCEA1HRA38P100T 1
C4701,4702 nsp
CAP, ELECT(100uF/50V, RA3,ELNA) A3-
50V101MG3#8P-T2
CCEA1HRA3101T 1
C4705,4706 nsp
CAP, ELECT(47UF/50V, RA3, ELNA ) A3-
50V470MF3#8P-T2
CCEA1HRA3470T 1
C4710,4711 nsp
CAP, ELECT(47UF/50V, RA3, ELNA ) A3-
50V470MF3#8P-T2
CCEA1HRA3470T 1
C4713,4714 nsp
CAP, ELECT(47UF/50V, RA3, ELNA ) A3-
50V470MF3#8P-T2
CCEA1HRA3470T 1
C4727,4728 nsp
CAP, ELECT(100uF/50V, RA3,ELNA) A3-
50V101MG3#8P-T2
CCEA1HRA3101T 1
C4729,4730 nsp
CAP, ELECT(10uF/100V), ELNA/RA3 A3-
100V100E3#8P-T2
CCEA2ARA3100T 1
C4761-4768 nsp
CAP, ELECT (10uF/50V, 6.3X11, RA3)
00MF3#8P-T2
CCEA1HRA38P100T 1
C4773,4774 nsp
CAP, ELECT (10uF/50V, 6.3X11, RA3)
00MF3#8P-T2
CCEA1HRA38P100T 1
C4781,4782 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C4801,4802 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C4811,4812 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C4825-4828 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C4831,4832 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C4841,4842 nsp CAP, ELECT(50V/4.7uF) CCEA1HH4R7T 1
