PARTS LIST OF PCB UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:
The symbols in the column "Remarks" indicate the following destinations.
U : North America model N : Europe model K : China model
B : Black model SG : Silver gold model
FRONT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D6021 90M-HD302360R DIODE , ZENER ,1/2W, 6.8V CVDZJ6.8BT 1
D6023,6024 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D6026 943202007690S DIODE , ZENER ,1/2W, 18V CVDZJ18BT 1
D6027 00D9430087209 DIODE , ZENER ,1/2W, 24V CVDZJ24BT 1
D6029,6030 90M-HI101190R BLUE L.E.D CVD52CSBBCEAB2 1
D6033,6034 90M-HI101190R BLUE L.E.D CVD52CSBBCEAB2 1
D6037,6038 263010046507S LED , SUPER RED CVDBLBUF4V5K1AV 1
D6039-6041 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D6453-6455 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI1 1
D6712 00D2760694903 DIODE , ZENER (CHIP,5.1V) HVDUDZS5.1BSR 1
D6729,6730 00D2760694903 DIODE , ZENER (CHIP,5.1V) HVDUDZS5.1BSR 1
IC601 00D2631289900
I.C , OPAMP(DUAL/LOW NOISE)_Copper
Z4580MTR-E1-CU
CVIAZ4580MTR-E1-CU 1
IC603 963231101200S I.C, REGULATOR(ADJ/TO-252) CVINJM2887DL3 1
IC607 00D2631289900
I.C , OPAMP(DUAL/LOW NOISE)_Copper
Z4580MTR-E1-CU
CVIAZ4580MTR-E1-CU 1
Q6005 943219006820S TR KTC1027Y CVTKTC1027YT 1
Q6011 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6014-6016 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6042 943214500020S T.R,2SC3052 CVT2SC3052 1
Q6081 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6112 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C 1
Q6153 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6313,6314 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6702 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
CAPACITORS GROUP
C1003-1006 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C1008-1012 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C1017 nsp CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC 1
C1018-1020 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6007,6008 nsp CAP, ELECT(63V/470uF) CCEA1JH471E 1
C6014 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6021 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C6022,6023 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6025 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C6027 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C6034 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6046 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C6052 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C6071-6073 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C6081 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
