Marantz AV7701 - Front Hdmi Pcb Unit Assy

215
FRONT HDMI PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 nsp I.C, HDMI BUFFER CVIAD8195ACPZ 1
CAPACITORS GROUP
C1007 nsp CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC 1
C1013 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C1014 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C1015 nsp CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC 1
C1016 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
RESISTORS GROUP
R1001 00MNN05102610 RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1002 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R1007 00MNN05473610 RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R1012,1013 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R1022 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
OTHERS PARTS GROUP
BK103 nsp EARTH , HDMI CMC1A436 1
CN101 nsp
WAFER, FFC, SMD(23P-1mm,
STRAIGHT)
CJP23GA193ZY 1
JK101 943643101930S JACK, HDMI(KSI-TWI, W/O FLANGE) CJJ9H015Z 1
L1001,1002 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
18301001910AS MODULE , HD RADIO U CNVKRMAVR2011 1
