Marantz AV7701 - Parts List of Packing & Accessories

175
PARTS LIST OF PACKING & ACCESSORIES
z
Parts indicated by "nsp" on this table cannot be supplied.
z
Parts indicated by the "
★
" mark are not illustrated in the packing view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:
The symbols in the column "Remarks" indicate the following destinations.
U : North America model N : Europe model K : China model
B : Black model SG : Silver gold model
Ref. No. Part No. Part Name Remarks Q'ty New
1 943531102960M BOX, OUT CARTON CPG1A965Y 1 *
2 nsp BAG , POLY CPP1A081X 1
3 943533101230M PAD , SNOW TOP CPS1A918 1
4 943533101240M PAD , SNOW BOTTOM CPS1A919 1
z
5 943611500590S CORD , POWER (PLUG+SOCKET) UL U CJA2A119Z 1
z
5 943611500580S CORD , POWER (PLUG+SOCKET) EUR N CJA2B120Z 1
z
5 90M-ZC000650R CORD , POWER K CJA2N075Z 1
6 32401000800AD MIC , AUDYSSEY CJXACM1HB 1
7 - INSTRUCTION MANUAL ASS'Y - 1
7-1 nsp BAG, POLY CQB1A197Z 1
7-2 54111097900AM MANUAL, GUIDE U CQX1A1700Z 1 *
7-2 54111097901AM MANUAL, GUIDE N CQX1A1701Z 1 *
7-2 54111097903AD MANUAL, GUIDE K CQX1A1702Z 1 *
7-3 nsp WARRANTY CARD, CHINA K CQE1A132V 1
7-3 nsp CARD FOR CHINA INDENTIFICATION K CQE1A450Z 1
7-4 nsp CARD , WARRANTY U CQE1A131W 1
7-5 35201019200AM CD MANUAL ASS'Y U CFT1A074ZA 1 *
7-5 35201019201AM CD MANUAL ASS'Y Disc1 N CFT1A075ZA 1 *
7-5 35201019205AM CD MANUAL ASS'Y Disc2 N - 1 *
7-5 35201019203AM CD MANUAL ASS'Y K CFT1A076ZA 1 *
7-6 nsp BATTERY , AAA 2PCS IN PACK CABR03PPB 2
7-7 30701010000AM REMOCON ASS'Y(RC016SR) CARTSR7007 1
7-8 90M-ZA000230R FM 1 POLE ANT(UL) U CSA1A019Z 1
7-8 00D9430113403 FM 1 POLE ANT N,K CSA1A018Z 1
7-9 943116100090S ANT, AM LOOP(HD RADIO, 105uH/18T) U CSA1A040Z 1
8 nsp TAPE , P.P(24mm*50mm) C4FC240CL 1
9 nsp TAPE , OPP C4FC500CL 2
10 nsp POP LABEL UN CQB1A1104X 1 *
10 nsp POP LABEL K CQB1A1104W 1 *
11 nsp TAPE , FILAMENT C4FE187 0.2
12 nsp LABEL, CONTROL CQB2A993Z 2
12-1 nsp LABEL, SERIAL CQB1A993Z-1 1
12-2 nsp LABEL, YEAR K CQB1A993Z-2 1
13 nsp LABEL, MAC ADDRESS CQB1A995 1
