Marantz AV7701 - Smps Pcb Unit Assy

216
SMPS PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D9001-9006 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D9008,9009 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D9010 00D9430182609 DIODE , SWITCHING, 1SS133 CVD1SS133MT 1
D9012 943209500030S
DIODE, LOW FORWARD SCHOTTKY
RECTIFIER
CVDSRL3060P 1
D9013 963209010430S DIODE, RECTIFIER (1000V) CVDAP01CT 1
z
IC901 231010091708S I.C , OFF-LINE POWER SWITCH CVITOP258MG 1
z
IC902 963239010480S I.C , PHOTOCOUPLER CVIPC123Y22FZ0F 1
IC903 212050010508S I.C , SHUNT REGULATOR(TO-92) CVIKIA2431AP 1
Q9001-9003 00D9430154404 TR KTC3198Y HVTKTC3198YT 1
ZD901 00D2760762958 DIODE , ZENER ,1/2W, 39V U CVDZJ39BT 1
ZD901 nsp RES, CARBON(1/5W,1Mohm,J) N/K CRD20TJ105T 1
ZD902 00D2760762958 DIODE , ZENER ,1/2W, 39V U CVDZJ39BT 1
ZD902 nsp RES, CARBON(1/5W,1Mohm,J) N/K CRD20TJ105T 1
ZD903 963202010440S DIODE , ZENER ,1/2W, 22V U CVDZJ22BT 1
ZD903 00D2760762958 DIODE , ZENER ,1/2W, 39V N/K CVDZJ39BT 1
ZD904 00D2760762958 DIODE , ZENER ,1/2W, 39V N/K CVDZJ39BT 1
ZD905 00D2760762958 DIODE , ZENER ,1/2W, 39V N/K CVDZJ39BT 1
ZD906 00D2760762958 DIODE , ZENER ,1/2W, 39V N/K CVDZJ39BT 1
ZD907-910 00D2760762958 DIODE , ZENER ,1/2W, 39V N/K CVDZJ39BT 1
ZD911-918 963202010440S DIODE , ZENER ,1/2W, 22V CVDZJ22BT 1
ZD919 00D9600095607 DIODE , ZENER ,1/2W, 5.6V CVDZJ5.6BT 1
ZD920 00D2760762958 DIODE , ZENER ,1/2W, 39V CVDZJ39BT 1
CAPACITORS GROUP
C4661,4662 nsp CAP, CHIP(1608, 50V/100pF) N/K CCUS1H101JA 1
C4665,4666 nsp CAP,CHIP(1608,50V/220pF) CCUS1H221JA 1
C4803-4806 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C4819,4820 nsp CAP, CHIP(1608, 50V/68pF) CCUS1H680JA 1
C4823,4824 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C4837,4838 nsp CAP, CHIP(1608, 50V/3300pF) CCUS1H332KC 1
C4839,4840 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C4853-4856 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C4869,4870 nsp CAP, CHIP(1608, 50V/68pF) CCUS1H680JA 1
C4873,4874 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C4887,4888 nsp CAP, CHIP(1608, 50V/3300pF) CCUS1H332KC 1
C4889,4890 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
z
C9001-9003 963132011940S CAP, CERAMIC(X1/Y2,0.01uF,AC250V) CCKDKY103MFM 1
C9004 943134501590S CAP, ELECT(200V/100uF),105'C U CCET200NHA101ES 1
C9004 963134010200S CAP , ELECT (400V/100UF, 18X40, NHA) N/K CCET400NHA101ES 1
C9006-9008 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C9009 00D9430175108 CAP, ELECT(50V/10uF),105'C CCEA1HNXA100TS 1
C9010 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C9012 963132010120S CAP, CERAMIC(DC1KV/1000pF) CCKDDEH102KCM 1
C9016 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C9017 00MOA47602520 CAP, ELECT(25V/47uF),105'C CCEA1ENXA470TS 1
C9018 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
