Marantz AV7701 - Video Pcb Unit Assy

222
VIDEO PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D1202-1204 nsp
ESD SUPPRESSOR
(ASQS 12U 02 0R2, 0.2pF/12V 1005)
CLZ9Z120Z 1
D1501 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D2301 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D3002 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D3301,3302 943209001080S DIODE , CHIP , SWITCHING 1SS355 CVD1SS355T 1
D5161 00D2760718902 DIODE, SCHOTTKY, 30V CVDRB521S-30 1
D5211 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D5212 943202000940S DIODE , ZENER ,1/2W, 16V CVDZJ16BT 1
D5221 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D5222 943202000940S DIODE , ZENER ,1/2W, 16V CVDZJ16BT 1
D5256 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D5257 90M-HI200020R INFRARED L.E.D BVDSIR34ST3F 1
D5312 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
IC156 943239010400S I.C, REGULATOR(1.8V/TO-252) CVINJM2845DL118 1
IC202 943239100720S I.C , EEPROM(256KBIT,SOP-8P) CVIR1EX24256BSAS0A 1
IC308 943239100730S I.C , SYSTEM RESET(4.8V , SOT-25A) CVIPST8448NR 1
IC310 943239010400S I.C, REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC320 943239100710S I.C,CURRENTLIMITE(1.5A,UDFN-6P) CVINCP380HMU15AATBG 1
IC392,393 963246100740D I.C , SDRAM(256M,8BIT,TSOP-54P) CVIA3V56S30FTP-G6 1
IC407 236810083506S I.C , CLOCK JITTER CVICS210010-CZZR 1
IC409 943246012690S I.C , 64M SDRAM CVIW9864G6JH-6 1
IC441 236810073509S I.C, DAC(8CH 192kHz 24-Bit) CVIAK4358VQ 1
IC442 00D2631289900
I.C , OPAMP(DUAL/LOW NOISE)_Copper
Z4580MTR-E1-CU
CVIAZ4580MTR-E1-
CU
1
IC447 00D2631289900
I.C , OPAMP(DUAL/LOW NOISE)_Copper
Z4580MTR-E1-CU
CVIAZ4580MTR-E1-
CU
1
IC511 235810046603S IC , MULTI INPUT VIDEO CVIAVDM2000 1
IC513 943239010400S I.C, REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC521 963239008800S I.C, RS232 (3.3V) CVIILX3232DT 1
IC522,523 00D2631286903 I.C , REGULATOR (12V) CVIPQ120DNA1ZPH 1
IC531 943239010400S I.C, REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC532 00D2631289900
I.C , OPAMP(DUAL/LOW NOISE)_Copper
Z4580MTR-E1-CU
CVIAZ4580MTR-E1-
CU
1
Q1508 943214500020S T.R,2SC3052 CVT2SC3052 1
Q2304,2305 943214500020S T.R,2SC3052 CVT2SC3052 1
Q2306 943214500030S T.R , MUTE CVTINC2001AC1 1
Q2401 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q3007 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q3012 00D2710326904 T.R,2SA1954 CVT2SA1954 1
Q3013 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q3033 00D2710326904 T.R,2SA1954 CVT2SA1954 1
Q3034 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q3035 943214500020S T.R,2SC3052 CVT2SC3052 1
Q3038 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q3900 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C 1
Q3901 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q4001 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q5253 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q5311 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C 1
