14
(4) Disconnect the connector wire and FFC.
(5) Remove the screws, then detach the FRONT BRACKET.
(6) Remove the screws.
STYLE PIN : Loosen
FFC BN321
Shooting of photograph: A
Shooting of photograph: A
FRONT BRACKET
Shooting of photograph: A
EARTH DOOR
FRONT BRACKET
FRONT BRACKET
