180
Pin Pin Name Symbol I/O
Pull up/
down
LvCnv STBY STOP
CEC
STBY
Function
135 P45/IRQ13-B/AN5 KEY3 I SW3VPu I I I Button input 3
136 P44/IRQ12-B/AN4 KEY2 I SW3VPu I I I Button input 2
137 P43/IRQ11-B/AN3 KEY1 I SW3VPu I I I Button input 1
138 P42/IRQ10-B/AN2 E SPI REQ I Pd I L I
ETHERNET communication control
pin(DM860)
139 P41/IRQ9-B/AN1 NC O L L L NC
140 AVSS AVSS - - - - GND
141 P40/IRQ8-B/AN0 NC O L L L NC
142 VREF VREF - - - -
Reference voltage (+3.3V) input pin for
A/D port
143 AVCC AVCC - - - - +3.3V
144
P05/IRQ13-A/TMO3/
RxD4/TCK
TCK/RXD
MITSUBISHI/
NC(NORMRAL)
I/I/I M3VPu -/-/I -/-/I I
E20 Emulator control signal/ Mitsubishi
Programer/Nomal OP.:Input
