Marantz AV7701 - Page 19

19
(3) Cut the wire clamp band, then disconnect the connector wires and the FFC.
Remove the PCB HDMI from the PCB FRONT CNT and PCB SIDE CNT (Board to board).
(4) Disconnect the connector wire. Remove the screws.
CN321
FFC
FFC
cut
STYLE PIN : Loosen
Shooting direction: C
