1.4. Version display on the Setup Menu

Usethefollowingproceduretodisplaythermwareversion.

(1) Press the "SETUP" button on the remote control.

(2) Select "General-Information-Firmware".

A version with 20 digits is displayed as shown in the following image.

The displayed 20 digits are derived from each device version as shown below

 ThisrmwareversionNo.(xxxx-xxxx-xxxx-xxxx)isincludedintheservicecontactdocument.

These 20 digits are also included in the document.

5798-0207-0000-6810-09418900mocμniaM

Subμcom 60100068

DSP 7310

A.PLD 1804

GUI 60110057

DM860 FBL 090311

DM860 SBL B 201201250941

DM860 IMG I 201204030207

The 2nd digit from the right for Main μcom

The 1st digit from the right for Main μcom

The 2nd digit from the right for Sub μcom

The 1st digit from the right for Sub μcom

The 2nd digit from the right for DSP

The 1st digit from the right for DSP

Info display

The 1st digit from the right for SBL

The 2nd digit from the right for SBL

The 3rd digit from the right for SBL

The 4th digit from the right for SBL

The 1st digit from the right for IMG

The 3rd digit from the right for IMG

The

4th digit from the right for IMG

The 1st digit from the right for GUI

The 2nd digit from the right for GU

The shaded part

is not used.

The 2nd digit from the right for IMG

GUI Image

1490-0186-0000-7020-8975

Displays system information

General/Firmware

Version
