Display
q Play mode indicator
3:Thisindicatorlightsupduringpause.
1:Thisindicatorlightsupduringplayback.
w Main display area
Thisareadisplaysthetimedisplayandtext
information of the disc to be played, as
wellasthesettingmenuitems,etc.
e Time mode indicator
REMAIN:This indicator lights up while
the remaining track time is
displayed.
TTL:Thisindicatorlightsupwhilethetotal
remainingtime.
r Digital output o indicator (D OFF)
This indicator lights up when the digital
outputsettingissettoo(vpage16).
t USB indicator
Thisindicatorlightsupduringoperationin
theUSBmode.
y Disc indicator
Thisindicatordisplaysthedisctypewhich
iscurrentlyinthedisctray.
“M FILE” lights up if the disc contains
WMA/MP3les.
u TRK indicator
This indicator lights up above the display
ofthetracknumbercurrentlybeingplayed.
i Special play mode indicator
1:This indicator lights up during repeat
playofonetrack.
RPT:Thisindicatorlightsupduringrepeat
play.
ALL:Thisindicatorlightsupduringrepeat
playofalltracks.
RNDM:This indicator lights up during
randomplay.
PROG:This indicator lights up during
programplay.
o Filter indicator (FIL 1 2)
Thisindicatorshowswhichlter(Filter1or
Filter2)isselected(vpage23).
yoiutr e
Part names and functions
Rear panel
q AUDIO OUT connectors
Usedtoconnecttoanamplier
(vpage8).
w DIGITAL AUDIO OUT connectors
(COAXIAL/OPTICAL)
Used to connect to a device with digital
audioinputconnectors(vpage9).
e DIGITAL AUDIO IN connectors
(COAXIAL/OPTICAL/USB-DAC)
Used to connect to a device with
digital audio output connectors or a PC
(vpage9).
r REMOTE CONTROL IN / OUT
connectors
Used to connect to a Marantz amplier
thatiscompatiblewiththeremotecontrol
function(vpage11).
r t yq w e
t EXTERNAL/INTERNAL switch
Turn this switch to “EXTERNAL” to
operate the unit by pointing the remote
control at the amplier connected to this
unit using the remote control connection
(vpage11).
y AC inlet (AC IN)
Usedtoconnectthepowercord
(vpage12).
