Marantz SR5008/U1B - Page 83

Input
CVBS/COMPONENT
A
Check the input signal to
VIDEO DECODER.
Issignalconrmedforthe
following point?
HDMI B'D
V : R1309
COMPONENT-Y : R1306
COMPONENT-Cb : R1308
COMPONENT-Cr : R1307
Check the connections between
boards.
Input CVBS: Check B
Input COPONENT : Check C
Output CVBS NG : CheckB-4
Output COMPONENT NG : Check C-4
NO NO
YES
