2 Progressive Mode
Set an appropriate progressive conversion mode for the source video
signal.
Auto (Default) : The video signal is automatically detected and the
appropriate mode is set.
Video : Select mode suitable for video playback.
Video and Film : Select mode suitable for video and 30-frame film
material playback.
%
•This item can be set when “i/p Scaler” is set to anything other than “O”.
2 Aspect Ratio
Set the aspect ratio for the video signals output to the HDMI.
16:9 (Default) : Output at 16:9 aspect ratio.
4:3 : Output at 4:3 aspect ratio with black bars on the sides of a 16:9 TV
screen (except for 480p/576p output).
%
•“Aspect Ratio” can be set when “i/p Scaler” is set to anything other than
“O”.
Component Video Out
Set the zone to which the component video output connector is assigned.
MAIN ZONE (Default) : Assigns the component video output connector
to MAIN ZONE.
ZONE2 : Assigns the component video output connector to ZONE2.
