30
Appendix
TipsSettingsPlayback
Contents
Front panel Display Rear panel IndexRemote
Connections
%
•This unit is compatible with Audyssey DSX® (vpage 257), Dolby Pro Logic gz
(vpage 259) and DTS Neo:X (vpage 260) which oers an even wider and
deeper surround sensation.
When using Audyssey DSX®, install front wide speakers or front height speakers.
When using Dolby Pro Logic gz, install front height speakers.
•Use the illustration below as a guide for how high each speaker should be installed.
The height does not need to be exactly the same.
z1
z2
45˚
Surround
speaker
2 – 3 ft/
60 – 90 cm
GViewed from the sideH
Front height
speaker
•Point slightly
downwards
At least
3.3 ft/1 m
Surround back
speaker
•Point slightly
downwards
Front
speaker
Front wide
speaker
z1 Recommended for Dolby Pro Logic gz
z2 Recommended for Audyssey DSX®
NOTE
•Sound cannot be played simultaneously from all of the surround back, front height
and front wide speakers.
