Model WT3-201M Motorized Wire Crimp Pull Tester User’s Guide
1 LIST OF INCLUDED ITEMS
Certificate of calibration without data (standard) or with data (optional)
USB driver, MESUR
®
Lite software, MESUR
®
gauge evaluation software, User’s Guide
Download at: www.mark-10.com/resources
2 SAFETY
The following safety checks and procedures should be performed before and during operation:
1. Always consider the characteristics of the sample being tested before initiating a test. A
risk assessment should be carried out beforehand to ensure that all safety measures have been
addressed and implemented.
2. Wear eye and face protection when testing. Be aware of the dangers posed by potential
energy that can accumulate in the sample during testing. Extra bodily protection should be worn if
a destructive failure of a test sample is possible.
3. Keep away from moving parts of the tester. Loose articles of clothing should not be worn.
Long hair should be covered to avoid a hazardous situation.
4. In those applications which could lead to a hazardous situation, use of a machine guard
is strongly recommended.
5. When the tester is not in use, ensure that the power is turned off to prevent accidental
engagement of any of the controls.
Safety features provided by this tester may be impaired if it is not used in a manner not specified
by Mark-10.
3 SETUP
3.1 Mechanical Setup
3.1.1 Assembly
The tester is shipped completely assembled.
3.1.2 Mounting and placement
Place the tester on a clean, flat and level work area free from vibration. If desired, the tester can be
secured to the work area with four 1/4-20 screws fastened into the threaded holes in the underside of the
base (depth of 0.5 in. [12 mm]).
Ensure that the rear of the tester is easily accessible, so that the power cord can be disconnected in an
emergency.
3.1.3 Installing the ring terminal fixture or blank terminal fixture
To install or uninstall the standard terminal fixture or optional fixture, loosen the screw in the center of the
fixture, remove, place the other fixture in the receptacle, and re-tighten the screw. Keep away from metal
particles that may have originated from testing samples, as there are magnets located inside the terminal
fixtures.
