Model WT3-201M Motorized Wire Crimp Pull Tester User’s Guide
22 FUNCTION ACTIVATION
A number of optional functions are available, which may be ordered upfront or enabled in the field via an
activation code.
22.1 Demo Mode Functions
The WT3-201M is shipped in Demo Mode, which provides full functionality of all available functions for an
evaluation period of 160 operating hours. When this period has expired, any functions not purchased will
no longer be accessible.
After the initial power-up sequence, the display appears as follows:
An additional 160-hour demo period can be enabled when the original 160 hours have expired. To do so,
select Reset Demo Time from the Function Activation menu shown in the next sub-section, and follow
the request code / activation code procedure described.
22.2 Activating Functions
Select Function Activation from the menu. The display appears as follows:
Functions marked with an asterisk are installed. To install another function, scroll to it, then press ENTER.
The display appears as follows:
Supply the request code to Mark-10 or a distributor, who will then provide a corresponding activation code
to activate the function. Use the
and keys to select each character, then press DATA to
advance to the next character. Press ENTER when done. If the code has been entered successfully, the
function will be permanently installed.
Load Holding
Request code
1234567
Activation code
Profiles
* Pull to Load
Load Holding
* Date & Time Stamp
All Functions
All functions are
temporarily enabled.
Remaining demo time:
160 hours
Press ENTER.
