Model WT3-201M Motorized Wire Crimp Pull Tester User’s Guide
37
25 SPECIFICATIONS
25.1 General
Force capacity x resolution:
200 x 0.1 lbF | 3200 x 2 ozF | 100 x 0.05 kgF | 1000 x 0.5 N | 1 x 0.0005 kN
Accuracy: ±0.2% of full scale
Wire diameter range:
AWG30 - AWG 3 [0.01 - 0.25 in (0.3 - 6.3 mm)]
Min. sample length:
Minimum 6.5 in [165 mm], excluding termination
Max. elongation:
1.7 in [43 mm]
Speed range:
0.4 - 12.0 in/min [10 - 300 mm/min]
Sampling rate:
7,000 Hz
Speed setting accuracy:
±0.2%
Speed variation with load:
±0% [Stepper motor driven]
Power:
Universal input 100-240 VAC, 50/60 Hz, 200 W
Fuse:
1.2 A, 250V, 3AG, SLO BLO
Outputs:
USB / RS-232:
Fully configurable up to 115,200 baud.
Mitutoyo (Digimatic):
Serial BCD suitable for all Mitutoyo SPC-compatible devices.
Analog:
-1 VDC, ±0.25% of full scale at capacity,
General purpose:
Three open drain outputs, one input.
Set points:
Three open drain lines.
Safe overload:
150% of full scale (display shows “OVER” at 110% and above)
Weight:
26.5 lb [12 kg]
Included accessories:
Power cord, quick-start guide, USB cable, and NIST-traceable certificate of calibration.
Environmental conditions:
- Indoor use only
- Up to 6,500 ft [2,000 m] above sea level
- Temperature range: 40 - 100°F [5 - 40°C]
- Humidity range: up to 80% relative humidity at 31°C, decreasing linearly to 50%
relative humidity at 40°C, non-condensing
- Mains supply voltage fluctuations up to ±10 % of the nominal voltage
- Transient overvoltages up to the levels of Overvoltage Category II
- Use in environments up to Pollution Degree 2
Warranty:
3 years (see individual statement for further details)
Literature & Software:
Download at: www.mark-10.com/resources
