Model WT3-201M Motorized Wire Crimp Pull Tester User’s Guide
27
20 PASSWORDS
Two separate passwords may be configured to control access to the Calibration section and to the menu
and other keys. To access the passwords setup screen, select Passwords from the menu. The display
appears as follows:
20.1 Calibration Password
Select Calibration from the sub-menu. The display appears as follows:
To set the password, select Enabled, then Set Password. Use the UP and DOWN keys to increment and
decrement the value, from 0 to 9999. When the desired value has been selected, press ENTER, then
ESC to exit the sub-menu.
20.2 MENU Key Password
If enabled, every time the MENU key is selected, a password must be provided. Select MENU Key from
the sub-menu. Follow the same procedure as described in the previous sub-section.
20.3 Locking Out Other Keys
Other keys may be locked out individually. Select any combination of keys (MODE, ZERO, DATA) by
pressing ENTER in the Passwords sub-menu. Pressing a locked key will prompt the message “KEY
PROTECTED” and then revert to the previous screen.
CALIBRATION PASSWORD
* Disabled
Enabled
Set Password
(0000 – 9999)
5000
PASSWORDS
Calibration
MENU Key
MODE Key
ZERO Key
DATA Key
