Model WT3-201M Motorized Wire Crimp Pull Tester User’s Guide
4 HOME SCREEN AND CONTROLS
4.1 Demo Mode Functions
The WT3-201M is shipped in Demo Mode, which provides full functionality of all available optional
functions for an evaluation period of 160 operating hours. When this period has expired, any functions not
purchased will no longer be accessible.
After the initial power-up sequence, the display appears as follows:
The available optional functions are as follows:
1. Profiles
Save and recall sets of test parameters, such as speed, pass/fail limits, unit of measurement, etc.
Maximum of 500 profiles may be stored.
2. Load Holding
The tester will stop and maintain a specified load for a specified period of time.
3. Pull To Load
The tester will stop when the specified load has been reached.
4. Date & Time Stamp
A date and time stamp is assigned to each saved data point.
Refer to the Function Activation section for further instructions on how to activate functions.
All functions are
temporarily enabled.
Remaining demo time:
160 hours
Press ENTER.
