Model WT3-201M Motorized Wire Crimp Pull Tester User’s Guide
14 BREAK DETECTION
The break detection function senses when the wire-terminal separation occurs. A break is defined as a
force increasing beyond a configured force threshold, then decreasing to 2 lbF (or equivalent value in
other units). Upon detection of the break, the tester can stop and return at full speed to the Home
position, if Auto Return is enabled.
The tester can perform a number of additional automatic functions upon sample break, further described
in the Auto Settings section.
Break detection functions and settings are configured from a central location, and apply to any mode in
which it is enabled. Refer to the Operating Modes section for details on configuring each mode.
14.1 Configuration
To enable Break Detection, select Break Detection from the main menu. The display appears as follows:
Any combination of the above functions may be selected.
After exiting the menu, press ZERO to arm Break Detection. The message at the bottom of the screen
changes from “B” to “B ON”.
If tones are enabled, a tone will sound when the output, storage, and zero functions have been triggered.
Enabled
Enables the break detection function. When enabled, the letter “B” appears on the
home screen, between the Mode and Unit indicators. Refer to the Home Screen
and Controls section for details.
Threshold
Sets the percentage of full scale at which the break detection function becomes
active. This threshold is provided to ignore peaks that can occur during sample
loading and unloading.
Available settings: 1-90%, in 1% increments.
* Disabled
Enabled
Threshold 5 %
To Next Page
