Model WT3-201M Motorized Wire Crimp Pull Tester User’s Guide
19
16 AUTO SETTINGS
The tester can perform one or several functions automatically when it has returned to the Home position.
Return to Home can occur after a simple manual reverse, Auto Return, or a special event such as Break
Detection, Pull to Load, or Load Holding:
The following automatic functions are available
1. Save the peak value to memory.
2. Transmit the peak reading.
3. Toggle an output pin.
4. Zero the primary and peak readings after a settable delay.
Scroll to Auto Settings in the menu and press ENTER to set the value. The display appears as follows:
Enabled
When enabled, all individual settings marked with an asterisk are active. When
disabled, all settings are globally disabled, regardless of asterisks.
Memory Storage
Stores the peak reading to memory.
RS232/USB Output
Outputs the peak and date / time stamp (if this function is installed) via RS-232
and USB.
Mitutoyo Output
Outputs the peak via Mitutoyo.
Output Pin
Output Pin sets the selected SP1, SP2, or SP3 pin low until ZERO is pressed,
after which it reverts back to following the pass/fail limits if enabled. If not
required, select “NONE”.
Auto Zero
Zeroes the display.
Auto Zero Delay
Automatic zero is delayed for the specified period of time following return to
the Home position.
AUTO SETTINGS 2
Output Pin: NONE
* Auto Zero
Auto Zero Delay
5 sec.
AUTO SETTINGS
* Enabled
* Memory Storage
* RS232/USB Output
Mitutoyo Output
+ More
