Model WT3-201M Motorized Wire Crimp Pull Tester User’s Guide
17 DATA MEMORY AND STATISTICS
The WT3-201M has storage capacity of 2,000 data points. Readings may be stored, viewed, and output
to an external device. The most recent data point may be deleted. Statistics are calculated for the data
presently in memory.
To enable memory storage, select DATA Key from the menu, then scroll to Memory Storage and press
ENTER. Then exit the menu. In the home screen, the data record number 0000 appears below the
primary reading. Press DATA at any time to save the displayed reading. The record number will
increment each time DATA is pressed. If DATA is pressed when memory is full the message “MEMORY
FULL” will be flashed at the bottom of the display and a double audio tone will be sounded.
To view, edit, and output stored readings and statistics, select Memory from the menu. The display
appears as follows:
17.1 View Data
All the saved data points may be viewed. The record number is displayed, along with the corresponding
value and presently set unit of measurement.
17.1.1 Date & Time Stamp
If the optional Date & Time Stamp function is installed, pressing ENTER for the highlighted data point will
display the associated date and time stamp, as well as the profile name (if the optional Profiles function
is installed). The display appears as follows:
Load: 20.0 lbF
Date: 01/20/2015
Time: 11:35:08 AM
Prof: PROFILE123
0002 22.2 lbF
0003 24.6 lbF
0004 18.9 lbF
0005 20.0 lbF
0006 19.9 lbF
View Data
View Statistics
Output Load Data
Output Full Data
Output Statistics
To Next Page
