Model WT3-201M Motorized Wire Crimp Pull Tester User’s Guide
8
4.3 Controls
Primary
Label
Primary Function
Secondary
Label
Secondary Function
ENTER
Various uses, as described in the
following sections.
-
ZERO
Zeroes the primary reading and
peaks.
(UP)
Navigates up through the menu and
sub-menus.
MENU Enters the main menu. ESCAPE
Reverts one step backwards through
the menu hierarchy.
MODE
Toggles between measurement
modes.
(DOWN)
Navigates down through the menu
and sub-menus.
DATA
Stores a value to memory, transmits
the current reading to an external
device, and/or initiates automatic
data output, depending on setup.
DELETE
Enables and disables Delete mode
while viewing stored data.
START
Starts motion. Press and release to
produce maintained motion. In
Maintenance mode, a key press
results in momentary motion.
-
STOP Stops motion. RETURN
Reverses motion. Press and release
to produce maintained motion until
return to the Home position. In
Maintenance mode, a key press
results in momentary motion.
4.4 Menu navigation basics
Most of the tester’s various functions and parameters are configured through the main menu. To access
the menu press MENU. Use the UP and DOWN keys to scroll through the items. The current selection is
denoted with clear text over a dark background. Press ENTER to select a menu item, then use UP and
DOWN again to scroll through the sub-menus. Press ENTER again to select the sub-menu item.
For parameters that may be either selected or deselected, press ENTER to toggle between selecting and
deselecting. An asterisk (*) to the left of the parameter label is used to indicate when the parameter has
been selected.
For parameters requiring the input of a numerical value, use the UP and DOWN keys to increment or
decrement the value. Press and hold either key to auto-increment at a gradually increasing rate. When
the desired value has been reached, press ENTER to save the change and revert back to the sub-menu
item, or press ESCAPE to revert back to the sub-menu item without saving. Press ESCAPE to revert one
step back in the menu hierarchy until back into normal operating mode.
Refer to the following sections for details about setting up particular functions and parameters.
