OP32 – Installation manual
23
6. CONNECTING THE ORI RECEIVER
6.1 Installing the Receiver in the Machine
The E83 ORI may be mounted on the machine panel, or on the spindle, as illustrated below.
Figure 6-1. Installing the Receiver in the Machine.
6.2 Connecting the Compressed Air Hose
It is possible to clean the safety glass with compressed air, by connecting a pneumatic hose to the screw (see Figure
6-2).
Figure 6-2. Connecting the Compressed Air Hose.
Connect the pneumatic hose, to
the screw with the through hole
Cleaning air exit hole
Compressed air screw
