Martin MAC One - DMX protocols; Compact DMX Mode Overview

38 Martin
®
MAC One User Manual Rev. B
DMX protocols
Compact DMX Mode
20 DMX channels
In Compact mode, the Backlight LEDs follow colors and intensity from the Beam LED (unless disabled
using the Control/Settings channel).
Channel
DMX Value
Function
Fade
type
Default
value
1
0–19
20–49
50–200
201–210
211–255
Strobe/shutter
Shutter closed
Shutter open
Strobe (slow → fast)
Shutter open
Random strobe (slow → fast)
Snap
30
2
0–65535
Dimmer
Closed → Open
Fade
0
3
4
0–65535
Red
Intensity 0 → 100%
Fade
65535
5
6
0–65535
Green
Intensity 0 → 100%
Fade
65535
7
8
0–65535
Blue
Intensity 0 → 100%
Fade
65535
9
10
0–38
39
…
127
128
129
…
255
CTC
2 000 K
2 050 K
…
6 450 K
6 500 K
6 550 K
…
12 850 K
Fade
128
11
0
1–126
127–128
129–254
255
Tint (Green Magenta Shift)
Δuv - 0.05 (full shift towards magenta)
Δuv - 0.05 → Δuv 0.00
Δuv 0.00 (no shift - on black body curve)
Δuv 0.00 → Δuv + 0.05
Δuv + 0.05 (full shift towards green)
Fade
128
12
0–10
11–12
13–14
15–16
17–18
19–20
21–22
23–24
25–26
27–28
Virtual color wheel
Solid colors
Open
Moroccan Pink (LEE 790)
Pink (LEE 157)
Special Rose Pink (LEE 332)
Follies Pink (LEE 328)
Fuchsia Pink (LEE 345)
Surprise Pink (LEE 194)
Congo Blue (LEE 181)
Tokyo Blue (LEE 071)
Deep Blue (LEE 120)
Snap
0
