30 Martin
®
MAC One User Manual Rev. B
Control menus
Default settings are given in bold print.
Set DMX address (default address =
1). The DMX address range is limited
so that the fixture will always have
enough DMX channels within the 512
available.
Display fixture’s static IP address
Set far left block (most significant byte)
of IP address
Set middle left block of IP address
Set middle right block of IP address
Set far right block (least significant byte)
of IP address
Display fixture’s subnet mask
Set subnet mask with 1-bit increments
from the left
Display fixture’s MAC address
Reset static IP address and subnet
mask to factory default values
User-settable 4-digit fixture ID number
(default = 0)
Enable/disable pan/tilt limits
Set minimum pan angle limit
Set maximum pan angle limit
Set minimum tilt angle limit
Set maximum tilt angle limit
RESET PAN/TILT
LIMITS → ARE YOU
SURE? → YES/NO
Remove pan and tilt limits (reset pan
and tilt ranges to factory defaults)
