DMX protocols 53
P3-100 Segment Control Fixture
MSB = Most Significant Byte
LSB = Least Significant Byte
Single-channel control
The above DMX protocols apply to control sets, or blocks of controls, but should be used as a guide also to
single global or segment controls that use single DMX channels. For example, if you do not need any other
controls than 8-bit rotation and you drag Rotation (8-bit) over to the patch frame so that you can control
rotation on one single DMX channel, the DMX values required by that control will be as explained in the DMX
protocol above for channels 7/13.
8-bit
Basic
Mode
16-bit
Basic
Mode
8-bit
Extd.
Mode
16-bit
Extd.
Mode
DMX
Value
Function
1 1 1 1
0-255
Intensity MSB (fade) - Default value = 0
Zero → full
2 2
0-255
Intensity, fine LSB (fade) - Default value = 0
Lower → higher
2 3 2 3
0-255
Red MSB (fade) - Default value = 255
Zero → full
4 4
0-255
Red, fine LSB (fade) - Default value = 255
Lower → higher
3 5 3 5
0-255
Green MSB (fade) - Default value = 255
Zero → full
6 6
0-255
Green, fine LSB (fade) - Default value = 255
Lower → higher
4 7 4 7
0-255
Blue MSB (fade) - Default value = 255
Zero → full
8 8
0-255
Blue, fine LSB (fade) - Default value = 255
Lower → higher
5 9
0
↓
127-128
↓
255
X position (fade) - Default value = 127
Max. left
↓
No shift
↓
Max. right
10
0-255
X position, fine LSB (fade) - Default value = 255
Fine left → fine right
6 11
0
↓
127-128
↓
255
Y position (fade) - Default value = 127
Max. up
↓
No shift
↓
Max. down
12
0-255
Y position, fine LSB (fade) - Default value = 255
Fine up → fine down
7 13
0
↓
127-128
↓
255
Rotation MSB (fade) - Default value = 127
Full CCW
↓
No rotation
↓
Full CW
14
0-255
Rotation, fine LSB (fade) - Default value = 255
Fine rotation adjustment
Table 5: DMX protocol: segment control
