6 P3-100 user manual
Introduction
This manual explains how to connect and use the Martin Professional™ P3-100™ System Controller to
display video on a video panel installation that consists of Martin Professional™ EC-20™, LC Plus™ Series
or upgraded LC™ Series panels of one type only or used in combination. The manual corresponds to version
2.0 of the P3-100, LC Plus panels, LC panels upgraded to LC Plus spec and EC-20 panels software. In other
words, version 2.0 or later software needs to be installed both on the P3-100 and on panels.
For information about installing EC-20 or LC Plus panels, see the user documentation supplied with panels
and available for download from the Martin website at www.martin.com
The latest firmware updates and user documentation for all Martin Professional products are always available
from the Martin website.
Warning! Read “Safety Information” on page 3 before installing, powering or operating the
P3-100.
Thank you for selecting the Martin P3-100, a video processor for the EC™ and LC Plus™ Series of modular
LED-based IP65-rated video display panels from Martin Professional. This product features:
• Intuitive GUI (graphic user interface)
• DVI-I digital and composite, S-Video or component analog video input
• 500 000 pixel output resolution (expandable by stacking two or more P3-100s together)
• Genlock
• Image rotation
•Scaling
• De-interlacing
• Gamma curve adjustment
• Real-time control via DMX
• Real-time color temperature control
• Dynamic panel remapping
• P3-100 Offline Editor (PC application that lets you prepare an installation layout offline)
Comments or suggestions regarding this user manual may be e-mailed to service@martin.dk or posted to:
Technical Documentation, Martin Professional A/S, Olof Palmes Allé 18, DK-8200 Aarhus N, Denmark.
