Martindale ET4000 / ET4500 Technical specifications
71
9.3 RCD testing
9.3.1 General data
Nominal residual current (A,AC) ........ 10 mA, 30 mA, 100 mA, 300 mA, 500 mA,
1000 mA
Nominal residual current accuracy ..... -0 / +0.1I; I = IN, 2IN, 5IN
-0.1I / +0; I = 0.5IN
Test current shape ............................. Sine-wave (AC), pulsed (A, F)
DC offset for pulsed test current ........ 6 mA (typical)
RCD type ........................................... non-delayed, S (time-delayed)
Test current starting polarity ............. 0º or 180º
Voltage range .................................... 93 V  134 V (45 Hz - 65 Hz)
185 V  266 V (45 Hz - 65 Hz)
I

N
× 1/2 I

N
× 1 I

N
× 2 I

N
× 5 RCD I

I

N
(mA)
AC A, F AC A, F AC A, F AC A, F AC A, F
10
5 3.5 10 20 20 40 50 100
 
30
15 10.5 30 42 60 84 150 212
 
100
50 35 100 141 200 282 500 707
 
300
150 105 300 424 600 848 1500 n.a.
 
500
250 175 500 707 1000 1410 2500 n.a.
 
1000
500 350 1000 1410 2000 n.a. n.a. n.a.
 
n.a. ..................................................... not applicable
AC type .............................................. sine wave test current
A, F types…… ................................... pulsed current
9.3.2 Contact voltage RCD Uc
Measuring range to BS EN 61557-6 is 20.0 V - 31.0V for limit contact voltage 25V
Measuring range to BS EN 61557-6 is 20.0 V - 62.0V for limit contact voltage 50V
Measuring range (V) Resolution (V) Accuracy
0.0 - 19.9
0.1
(-0 % / +15 %) of reading ± 10 digits
20.0 - 99.9 0.1 (-0 % / +15 %) of reading
The accuracy is valid if the mains voltage is stable during the measurement and the PE
terminal is free of interferance voltages.
Test current ...................................... max. 0.5I

N
Limit contact voltage ......................... 25 V, 50 V
Specified accuracy is valid for the complete operating range.
