– User and Installation Manual
Total AC output voltage of the cluster on L1
Total AC output current of the cluster on L1
Total AC output frequency of the cluster on L1
Total AC output power of the cluster on L1
Mains input voltage on L2
Mains input current on L2
Mains input frequency on L2
Total AC output voltage of the cluster on L2
Total AC output current of the cluster on L2
Total AC output frequency of the cluster on L2
Total AC output power of the cluster on L2
5.2.2 Alarms tab
The following table lists the parameters as shown in MasterAdjust.
Internal temperature of the CombiMaster Inverter/Charger is too high.
An error has been detected in (one of) the fan(s).
Battery temperature too high / too low
Battery voltage is too high.
Battery voltage is too low.
The loads exceed the nominal inverter power
Internal CombiMaster Inverter/Charger error.
AC input voltage or frequency out of range
5.2.3 History tab
The following parameters are only shown in MasterAdjust.
Inverter mode operation hours
Charger mode operation hours
Parameters marked with a
are not available in CZone.
5.2.4 Configuration tab
The configuration can be done in MasterAdjust, from a laptop or notebook connected to the
CombiMaster Inverter/Charger via a Mastervolt USB Interface. See applicable user manuals for details.
The following table lists the parameters as shown in MasterAdjust.
Notes: - DIP switch settings overrule MasterBus settings. If DIP switches are not in their default setting,
the corresponding MasterBus setting is greyed out.
- To be able to make changes to the configuration via MasterBus, DIP switch 1 must be in the
ON position.
- Bulk, absorption and float settings are read only, unless battery type "user defined" is selected.
