– User and Installation Manual
9.4 Miscellaneous
IP 23 vertical wall mounted, IP 21 horizontal tabletop mounted
See also section 9.6
-13°F to 140°F, derating above 104°F, shutdown above 140°F
[-25°C to 60°C, derating above 40°C, shutdown above 60°C]
HT Models 4500W, 5000W:
-13°F to 176°F, derating above 104°F, shutdown above 176°F
[-25°C to 80°C, derating above 40°C, shutdown above 80°C]
-22°F to 158°F [-30 to 70°C]
HT Models 4500W, 5000W:
-22°F to 176°F [-30 to 80°C]
Max 95% relative humidity, not condensing.
Standards, approvals & listings
UL1741, UL1236, FCC Class B
Yes, shows AC input state, Inverter state, charger state
Battery temperature sensor
Models 3500W, 4500W, 5000W only *
Split-phase configuration
Models 3500W, 4500W, 5000W only *
Yes, conforming to SAE J1171/ISO 8846
Relay disconnects when frequency is out of range
Relay disconnects when voltage is out of range
Yes (integrated resettable thermal breaker)
Over temperature protection
* To increase the total power or to produce 240V. For information on multi-unit configurations, see
chapter 7.
9.5 CZone specifications
LEN (Load Equivalence Number): 0
PGN (Parameter Group Number):
Voltage, Current, Real Power
Voltage, Current, Real Power
Operating State, Charger Mode, Charge Enable/Disable
Battery Voltage, Battery Current, Battery Case Temperature
Operating State, Inverter Enable/Disable
