CombiMaster 120V Series –
User and Installation Manual
7.8 Breaking down a cluster
If a unit has to be removed from an existing cluster, use one of the following 3 procedures.
Using DIP switches:
a) Make sure the AC IN and AC OUT breakers are open.
b) Make sure the "On/Charge only"-switch position is "Charge only" () on all units.
c) On the unit to be removed, set DIP switch 10 to the OFF position (0).
d) Remove the Current Sharing and parallel Communication cables of the related unit.
e) For the settings to take effect, reconfigure the cluster.
Using MasterAdjust:
a) Make sure the AC IN and AC OUT breakers are open.
b) Make sure the "On/Charge only"-switch position is "Charge only" () on all units.
c) To return to fewer units per phase, change the Dev. per phase value and click Confirm topology
again.
To breakdown a cluster, select Single phase and 1 Device per phase and click the Confirm
topology button.
To remove a replica unit from the cluster, go to the Configuration tab of the related unit and click
the Detach button.
d) Remove the Current Sharing and parallel Communication cables of the related unit.
e) For the settings to take effect, reconfigure the cluster.
Using the CZone Configuration tool:
a) Make sure the AC IN and AC OUT breakers are open.
b) Make sure the "On/Charge only"-switch position is "Charge only" () on all units.
c) To breakdown a cluster, go to the Advanced Settings of the Primary unit and from the Cluster
Type drop-down list, select None.
d) Remove the Current Sharing and parallel Communication cables of the related unit.
e) For the settings to take effect, reconfigure the cluster.
