30
CombiMaster 120V Series
– User and Installation Manual
Value Meaning Default Adjustable Range
Float
Voltage
Float voltage
13.25
1)
12-15
1)
Return to Bulk
s
Delay time before the charger returns to
Bulk after reaching the Return to Bulk
voltage
30 s
0-600sec
Return to Bulk
V
Bulk return voltage. If the battery voltage
has dropped below this voltage, the
charger will return to bulk phase
12.80
1)
12-15
1)
AC IN
AC IN support
Option to enable AC input support mode
Off
On, Off
Max AC IN limit
Maximum value for the "AC IN Limit"
option on the monitoring tab
30A [50A]
2)
0-30A [0-50A]
2)
Input window
AC voltage range
Wide
Wide, narrow
AC IN limits

AC IN Limit A

Fuse pre-setting A
6A
0-30A [0-50A]
2)
AC IN Limit B

Fuse pre-setting B
10A
0-30A [0-50A]
2)
AC IN Limit C

Fuse pre-setting C
16A
0-30A [0-50A]
2)
Dry contact (installer level)
Function
Select dry contact alarm function
Alarm
Alarm, Power level
Power Level
Inverter output power level
60%
0-100%
Delay on
Delay on
5s
0-300 seconds
Delay off
Delay off
5s
0-300 seconds
Cluster (installer level, models 3500W, 4500W, 5000W only)
Phase system
Multi-unit configuration type
Single phase
Single phase, Split
phase
Dev. per phase
Number of devices per phase
1
1-7
Confirm
topology button
Button to confirm the number of devices
Cluster topology
Monitors whether the selected number of
devices equals the available number of
devices
Approved, Rejected
Activate cluster
button
Button to confirm the configuration
Cluster state
Monitors the configuration state
Activated, Cluster
conflict, Double
device, Incomplete,
Missing devices, Not
activated, Replica,
Standalone.
Processor 1
Version
Firmware DSP version
(read only)
Revision
Product version
(read only)
Bootloader ver.
Firmware bootloader version
(read only)
Processor 2
Version
Firmware MB version
(read only)
Bootloader ver.
Firmware bootloader version
(read only)
 Parameters marked with a  are not available in CZone.
1)
These values are for a 12V system. For a 24V system, multiply by 2. For a 48V system, multiply by 4.
2)
Models 1500W, 2000W, 3000W have a 30A fuse. Models 3500W, 4500W, 5000W have a 50A fuse.
