10 SPECIFIC AC CONFIGURATIONS
This chapter describes specific features of special installations
and options using the CS inverter. It was written to be an
addition to chapter 5 General Installation and Commissioning.
10.1 SUPPORTED COUNTRIES
In the next table, the selectable country codes are displayed.
COUNTRY
Netherlands
Belgium
France
Spain
Italy
Greece
Austria
Germany
Denmark
England
Ireland
Singapore
Taiwan
Korea
China
Custom
10.2 FUNCTION TEST FOR ITALIAN INSTALLATIONS
GENERAL
The Self Test Function is meant to check the upper and
lower limits of the AC voltage and AC frequency at which the
inverter will disconnect from the grid.
To enter the Self Test, enter the country selection menu in
the Grid Interface menu and choose Italy. In the Grid Inter-
face, select the Self Test menu.
During the self test, next tests are possible:
• Uac Max (high off limit AC voltage);
• Uac Min (low off limit AC voltage);
• Fac Max (high off limit AC frequency);
• Fac Min (low off limit AC frequency).
After each test you have to press Confirm before the inverter
starts the reclosure count down and reconnects to the grid.
The standard reclosure time of 300 sec has
been reduced to shorten the testing time.
This is not an error.
The test accuracy is better than 1V/ 0.1Hz if grid voltage and
frequency are stable.
