Matrix SETU ATA211 V1 System Manual 29
5. Program following parameters (for Location B)
• Click on 'Peer to Peer Call Table'. Program the number (say, 2001) assigned to the FXS port of the
ATA211 located at Location A.
• If the user are comfortable dialing IP Addresses directly after lifting the handset, Peer-to-Peer table
need to be programmed.
Residential Users: (Refer fig. 6)
Following steps should be done at both the locations:
Configure the Broadband Routers at both the locations as follows:
Configure the Routers in Bridge mode.
Configuring ATA211:
1. Open Web Jeeves of ATA211 by entering the LAN IP address of the ATA211 in the URL field and press
'Enter'.
2. Login as 'Admin' into the Jeeves of ATA211 using the Admin password (default 1234).You will reach the
Home Page.
3. Click on 'WAN Port' link and configure required parameters in the respective fields as mentioned below:
• Select 'Enable DHCP', if you want IP address, Subnet mask, and Gateway address to be assigned by
DHCP server automatically.
• Select 'Enable PPPoE', if your ISP provides internet services using PPPoE. Configure Username,
Password and Service Name provided by your ISP, if you have selected this option.
• Select 'Enable Static IP', if you want to assign IP address, Subnet Mask and Gateway address
manually. Configure all the fields manually if you have selected this option.
For more details, please refer topic “WAN Port”.
4. On 'SIP Accounts' program 'Enable SIP Account' for the SIP Account, which is to be used. Program the
parameter 'SIP Id' for this SIP Account as '*' (for configuring it as P2P Account).
5. Program following parameters in ATA211 (for Location A):
• Click on 'Peer to Peer Call Table'. Program the number (say, 3001) assigned to the FXS port of the
ATA211 located at Location B, as Destination SIP-ID Number.
• Program the IP address of broadband modem/ router located at the Location B.
• If the users are comfortable dialing IP addresses directly after lifting the handset, Peer-to-Peer table
need not be programmed.
6. Program following parameters in ATA211 (for Location B):
• Click on 'Peer to Peer Call Table'. Program the number (say, 2001) assigned to the FXS port of the
ATA211 located at Location A, as Destination SIP-ID Number.
• Program the IP address of broadband modem/router located at the Location A.
• If the users are comfortable dialing IP addresses directly after lifting the handset, Peer-to-Peer table
need not be programmed.
If you are stuck somewhere while configuring you SETU ATA211, you may default the system as
mentioned in the topic '"Reinstate the Default Settings" and start configuration process again.
