Matrix
SIMADO GFX11 System Manual
57
Flag Meaning
0OFF
1ON
By default, the Location Information Indication is OFF.
Step 5
Receive Gain
The GSM port provides a facility to adjust the receive gain. This
enables the user to increase the audibility of incoming speech.
Use the following command to program the receive gain of the GSM
port:
271-Receive Gain-#*
Where,
Receive Gain range from 1-5. Where, 1 is minimum and 5 is
maximum Gain.
Receive Gain Meaning
1 Very Low
2Low
3Normal
4High
5 Very High
By default, the Receive Gain is 3.
Use the following command to default the Receive Gain at the GSM
port:
271-0-#*
Step 6
Transmit Gain
The GSM port provides a facility to adjust the transmit gain. This
enables the user to adjust the right intensity for the transmitted
signal.
