Matrix simado gfx11 System Manual

Matrix
58
SIMADO GFX11 System Manual
Use the following command to program the transmit gain of the
GSM port:
272-Transmit Gain-#*
Where,
Transmit Gain range from 1-5. Where, 1 is minimum and 5 is
maximum gain.
Transmit Gain Meaning
1 Very Low
2Low
3Normal
4High
5 Very High
By default, the Transmit Gain is 3.
Use the following command to assign default value of the Transmit
Gain at the GSM port:
272-0-#*
Important Point:
• The actual dB values of Rx and Tx gain sent to GSM engine
depends on the type of GSM engine connected.
Relevant Topics:
1.
SMS 76
2.
Calling Line Identification Restriction 44
3.
Location Information Indication 63
4.
Network Selection 64
=X=X=

Matrix simado gfx11 Specifications

General

Brand	Matrix
Model	simado gfx11
Category	Gateway
Language	English
