SIMADO GFX11 System Manual
Step 2
Use the following command to program the network operator’s code
with priority:
332-Priority-Code-#*
Where,
Priority is from 1 to 4.
Code = MCC-MNC is of maximum 5 digits.
By default, Network Operator Code is Blank.
The default priority table, programmed in the system will be as
shown below:
Priority Network Operator Code
1 Blank
2 Blank
3 Blank
4 Blank
Use the following command to clear network operator code:
332-Priority-#*
Step 3
Use following command for selection of GSM Frequency Band:
333-GSM Frequency Band-#*
Where,
GSM Frequenc
y
Band Meanin
g
1 900
2 1800
3 1900
4 850 + 1900
5 900 + 1800
By default, GSM Frequency Band should be ‘900 + 1800’.
Example 1:
• You can program ‘850 + 1900’ GSM frequency band for countries
which support both 850 and 1900 MHz frequency bands for the
GSM network.
