C. Confi guring the Device
1. Install the Tubing Cartridge
To install a tubing cartridge:
1. When installing the tube set, make sure that the
adjustment screws are accessible. To do this, have
the screws on the top half when you lay out the tube
set so the adjustment screws will be toward the
middle of the pump when presented on the machine.
2. Push the blue PUSH button on the front of the tube
holder to open the mechanism.
Jaw is Open
