Max Bepop CPM-200G User Manual

7
Machine Preparation
MachinePreparation
LoadingtheTape
1
Pull up the opening/closing lever to open the door
cover.
5
Align the holes in the tape with the right and
left sprocket pins.
Opening/Closing Lever
Door Cover
Sprocket Pins
Ensure that the sprocket pins are inserted in the
sprocket holes in the tape and that the tape is
loaded straight on the roller.
If the sprocket pins are not inserted into the holes
or the tape is not straight, the tape will not be fed
properly.
2
Pull up the front lever.
Load the tape straight.
Front bar
Vinyl Holder
Yes No
3
Place the tape on the tape holder.
Vinyl
6
Lower the front lever to retain the tape.
Front bar
4
Pull the tape forward and feed it under the bar
at the front. Then, feed the tape further into the
rollers in the back.
Roller in the Back
Vinyl Retainer
Front bar
7
Close the door cover until it “clicks” to lock.
