DP-20 WEB GUIDE CONTROLLER USER MANUAL
www.maxcessintl.com
DP-20
MI 1-862 1 F
6
6-12
9. Use the ARROW keys to scroll to the desired
Measurement menu. Next in the list is the
DIGITAL INPUTS. The status of the inputs is
displayed on Line 4. The order in which the
inputs are displayed is 5,4,3,2,1,0.
10. Use the ARROW keys to scroll to the desired
Measurement menu. Next in the list is the
FIRMWARE VERSION. The version number of
the firmware is displayed on Line 4.
11. Use the ARROW keys to scroll to the desired
Measurement menu. Next in the list is the
SERIAL NUMBER. The serial number of the
DP-20 is displayed on Line 4.
12. If desired, use the ARROW keys to scroll until
EXIT MENUS is displayed on line 3. Pressing
the ENTER key while this screen is displayed
will exit the Measurement Menus and return to
the Operator Level.
13. Otherwise, press the MANUAL key to exit the
Measurement Menus and return to the
Operator Level.
Special Menus
3X.2.1, Deadband
1. Press the SETUP key to enter the Setup Menus.
The SELECT MENU screen will be displayed on
the LCD Panel.
2. Use the ARROW keys to scroll until SPECIAL is
displayed on line 4.
3. Press the ENTER key to enter the Special
Menus. The DEADBAND menu will be
displayed. The current value is displayed on
Line 4.
3C
MANUAL
×Ø -ãããããáÜÜÜÜ+
×Ø 3C.1.8.6
MEASUREMENT
DIGITAL INPUTS
000000
×Ø 3C.1.8.7
MEASUREMENT
FIRMWARE VERSION
DP-20 Ver 1.00
×Ø 3C.1.8.8
MEASUREMENT
SERIAL NUMBER
SN:01000
×Ø 3C.1.8.9
MEASUREMENT
EXIT MENUS
Ø 3B.1
SETUP (MAN)
SELECT MENU
BASIC
Ø 3B.2
SETUP (MAN)
SELECT MENU
SPECIAL
Ø 3B.2.1
SETUP (MAN)
DEADBAND
-ÜÜÜÜÜÜÜ+ 0.0%
