DP-20 WEB GUIDE CONTROLLER USER MANUAL
www.maxcessintl.com
DP-20
MI 1-862 1 F
7
7-1
7 PARALLEL MATRIX
Parallel Input Matrix
INPUTS
MODE
5
4
3
2
1
0
EXTERNAL LOCK
-
-
-
-
-
1
AUTOMATIC
-
-
0
0
1
-
MANUAL
-
-
0
1
0
-
SERVO-CENTER
-
-
1
0
0
-
JOG LEFT *
0
1
-
-
-
-
JOG RIGHT *
1
0
-
-
-
-
RGPC LEFT *
0
1
-
-
-
-
RGPC RIGHT *
1
0
-
-
-
-
RGPC RESET *
1
1
-
-
-
-
SENSOR, EDGE L OR LINE CENTER **
-
-
0
1
1
-
SENSOR, EDGE R OR LINE EDGE **
-
-
1
1
0
-
SENSOR, EDGE CENTER **
-
-
1
1
1
-
* Inputs 4 & 5 are used to provide Jogs while in Manual and Servo Center modes, and RGPC
functions while in Automatic mode.
** Sensor selection is allowed in Manual and Servo Center modes, only. Sensor selection
must be momentary commands. For sensor selection, input 2 must be commanded either
simultaneously with, or prior to, inputs 1 & 3.
0 = LOW
1 = HIGH
- = IGNORE
Parallel Output Matrix
OUTPUTS
STATUS
B*
A*
LOSS OF NULL (AUTOMATIC MODE)
-
1
CENTERED (SERVO-CENTER MODE)
1
-
* Parallel outputs are active low.
1 = ACTIVE
- = IGNORE
