DP-20 WEB GUIDE CONTROLLER USER MANUAL
LINE 2 While at the Operator Level, this line contains the name of the
currently selected Operation mode.
LINE 2 While in the setup menus, this line indicates that a Setup Menu
has been selected and also indicates the current Operation Mode.
LINE 3 While at the Operator Level, in either Automatic or Manual
mode, this line contains the symbol for the current sensor mode and also
a bargraph indicating the signal level of the currently selected sensor
mode. The sensor symbols are: × indicates Edge Left (X5 port); Ø
indicates Edge Right (X4 port); ×Ø indicates Center Guiding (both edge
sensors, X4 & X5 ports); ý indicates Center of Line guiding (X4 port);
and Ł indicates Edge of Line guiding (X4 port).
LINE 3 While at the Operator Level, in Servo-Center mode, this line
contains the Servo-Center sensor symbol (~ƒ) and also a bargraph
indicating the signal level of the Servo-Center sensor.
LINE 3 While in the Setup Menus, this line indicates the title of the
current menu selection.
LINE 4 While at the Operator Level, this line displays the Guide Point
value, if the value is not zero.
LINE 4 While at the Operator Level, in Automatic or Servo Center
mode, if ASC Control is set to ON, ASC is displayed on this line.
LINE 4 While at the Operator Level, in Automatic mode or Manual
mode, if ASC Control is set to ON, and if either one of the programmed
ASC Limits is reached, this line flashes ASC ACTIVE.
1A
AUTOMATIC
× -ãããããÜÜÜÜÜ+
× 3A.2.2
SETUP (MAN)
GUIDE POINT
-ÜÜÜÜåÜÜ+ +20.0%
1C
AUTOMATIC
×Ø -ãããããÜÜÜÜÜ+
× 2A
SERVO CENTER
~ƒ -ãããããÜÜÜÜÜ+
× 3A.1
SETUP (MAN)
GUIDE POINT
-ÜÜÜÜåÜÜ+ +20.0%
1A
AUTOMATIC
× -ãããããáÜÜÜÜ+
ASC ACTIVE
1A
AUTOMATIC
× -ãããããáÜÜÜÜ+
GP: +4.0%
1A
AUTOMATIC
× -ãããããáÜÜÜÜ+
ASC
