Section 2 - Installation
H6630EM-LIT 5 Rev. 1.0 11/14
Section 2 – Installation
2-1 Mounting
Mount the new H6630EM control panel in a convenient location for operation of the control screen.
Place the controller close enough to terminate the H5535-FDBK-20M (encoder cable) and H5535-
PWR-20M (motor cable) or H5535-PWRBRK-20M (motor cable with brake) to reach the control panel.
These cables route from the AC Servo Motor to terminal points in the control panel. Cables are typically
20 meters in length. Refer to the applicable H6630EM electrical drawings for termination points.
Figure 1 H6630EM Controller Mounting Dimensions
