Section 2 - Installation
H6630EM-LIT 7 Rev. 1.0 11/14
2-3 Connecting Power Wiring
CAUTION
Power feed and motor wiring shall be separated fro
cabling.
WARNING!
HIGH VOLTAGES ARE PRESENT! To avoid injury, DO NOT supply power to
the panel until installation has been completed!
Install conduit and route wiring for the incoming power to the L1, L2, and L3 terminals. Ensure the
system is grounded properly. All wiring must be in compliance with local and national electrical codes
and standards.
2-4 Connecting Peripheral Devices
Terminal blocks are provided for all field wiring. Detectors, sensors, offset potentiometers, motor and
encoder cabling and/or other external devices are shown on the applicable electrical schematic
supplied with the system or refer to the appendix in the H6630EM manual. Terminate ensuring each
device has good electrical and mechanical connection at the termination point.
