Maxcess H6630EM User Manual

Section 4 – Operation/Configuration/Calibration
H6630EM-LIT 23 Rev. 1.0 11/14
Post Calibration Steps
Verify the load limit setting is returned to 100%. Verify the Manual and Park RPM are set to the
desired RPM or speed, as desired, on the maintenance screen. Verify the software limits are
set correctly.
Automatic Operation
Once the unit is set up and calibrated, verify the automatic Gain is set to 50%; the unit can be
placed into auto from the HMI main screen. While providing some error of the strip as
compared to the zeroed control point, verify the actuator moves the guide in the direction to
correct the error. If not, change the “Auto Direction” on the maintenance screen.
Note: It will be necessary to have the guide system, process and guide, in a “closed loop” and moving with strip
tension to verify the guide brings the process to the control point.
While in “closed loop” operation, i.e., line in operation, adjust the “Auto Gain” to provide proper control.
CAUTION
If the Gain is set too high, the system will be unstable and oscillate. If it is set too
low, the response will be sluggish for most applications.
