Section 5 – Troubleshooting
Rev. 2.0 04/16 26 H6630EM-LIT
Keypad Navigation example:
Press the left/right or up/down arrow keys to scroll through the units parameters. The left/right
keys scroll through the 00 to 22 levels while the up/down scroll through the individual
parameters of the chosen level.
Press the left arrow key until the upper display reads 0.xx. Press the up arrow key until the
upper display reads 0.49. Press the “M” mode button once to allow changing of the setting in
the lower display. Use the up/down keys to select “L2”. Press the “M” key again to exit.
Note: Parameter 0.49 must be set to L2 to allow access of all parameters; otherwise the parameters available
are limited.
1001 Non-Volatile Save
The keypad can be used to perform a non-volatile save of any changed parameters by
performing the following: Press the left arrow key a couple times to display any level
parameter with an “xx00”. Press the ‘M’ key and change the lower level display to read
“1001” by using the left/right and up/down arrow keys. Now depress the “red” reset button.
Parameters used for Indication and Setting
00.49 Set to L2 to allow access of all parameters
03.25 Encoder Phase Angle
03.36 Encoder Supply Voltage
04.20 Percentage Load (Motor current % of Rated)
05.07 Motor Rated Current
07.10 Analog Input 1 reading
07.14 Analog Input 2 reading
07.18 Analog Input 3 reading
10.01 Drive OK
10.20-29 Last 10 Drive Trips
16.10-13 Drive IP Address
16.14-17 Drive Subnet Mask
16.32 Reinitializes Ethernet communications
16.37 Turns on Ethernet communications.
Maintenance Screens
The HMI has individual maintenance screens which provide additional or alternate indications of device
output readings or comp
onent status.
