Setting up
Connecting with your devices (continued)
(continued on next page)
Computer
Access
point
External
device
LAN
INOUT
SDI
COMPUTER IN 2
REMOTE
CONTROLHDBaseTHDMI 1DVI-DHDMI 2
CONTROLVH
B/Cb/Pb
G/YR/Cr/PrCOMPUTER IN 1
12V OUTPUT
(OPTION)
► Before connecting the projector to a network system be sure
to obtain the consent of the administrator of the network.
►
Do not connect the LAN port to any network that might have the excessive voltage.
CAUTION
• HDBaseT is a technology to transmit image, ethernet or serial control signal
via LAN cable.
• Use LAN cables of up to 100m long. Exceeding this length, the image will be
deteriorated, and even experience malfunction on LAN transmission.
- Quali ed cable is required for HDBaseT connection.
About HDBaseT™ connection
